Antioxidant and potential anti-inflammatory activity of extracts and formulations of white tea, rose, and witch hazel on primary human dermal fibroblast cells
Journal of Inflammation volume 8, Article number: 27 (2011)
Numerous reports have identified therapeutic roles for plants and their extracts and constituents. The aim of this study was to assess the efficacies of three plant extracts for their potential antioxidant and anti-inflammatory activity in primary human skin fibroblasts.
Aqueous extracts and formulations of white tea, witch hazel and rose were subjected to assays to measure anti-collagenase, anti-elastase, trolox equivalent and catalase activities. Skin fibroblast cells were employed to determine the effect of each extract/formulation on IL-8 release induced by the addition of hydrogen peroxide. Microscopic examination along with Neutral Red viability testing was employed to ascertain the effects of hydrogen peroxide directly on cell viability.
Considerable anti-collagenase, anti-elastase, and antioxidant activities were measured for all extracts apart from the witch hazel distillate which showed no activity in the collagenase assay or in the trolox equivalence assay. All of the extracts and products tested elicited a significant decrease in the amount of IL-8 produced by fibroblast cells compared to the control (p < 0.05). None of the test samples exhibited catalase activity or had a significant effect on the spontaneous secretion of IL-8 in the control cells which was further corroborated with the microscopy results and the Neutral Red viability test.
These data show that the extracts and products tested have a protective effect on fibroblast cells against hydrogen peroxide induced damage. This approach provides a potential method to evaluate the claims made for plant extracts and the products in which these extracts are found.
As the largest organ in the body, the skin provides a barrier against UV radiation, chemicals, microbes and physical pollutants. Challenges of this nature can contribute to skin ageing and inflammation which is characterised by oxidative damage [1–3]. Multiple studies have revealed that the skin is very sensitive to reactive oxygen species (ROS) [1–5]. Since an increase in the formation of the ROS hydrogen peroxide (H2O2) has been associated with inflamed and diseased tissues , H2O2 can be used to induce oxidative stress in cells and therefore may provide a method to evaluate antioxidant activity of plant extracts .
Many herbal extracts and natural products prevent or reduce oxidative stress in in vitro models. Mueller et al. screened 30 extracts from a wide range of plant families for their anti-inflammatory activities in macrophage cells . The reported anti-inflammatory mechanisms included reduction of the pro-inflammatory cytokines IL-6 and TNF-α, increasing anti-inflammatory IL-10 secretion, and reduction of cyclooxygenase-2 (COX-2) and nitric oxide synthase expression . Chilli pepper extract was shown to have the strongest anti-inflammatory activity along with allspice, apple, basil, bay leaves, black pepper and liquorice, to name but a few. These extracts all led to a reduction in IL-6 secretion. Dimethyl sulfoxide extracts of chilli pepper prevented TNF-α secretion and enhanced IL-10 production. Pure compounds such as apigenin, capsaicin, chrysin, kaempferol, and quercetin reduced IL-6 secretion . Carthamus tinctorius - a plant widely used to treat circulation problems has been found to prevent H2O2 -induced oxidative stress in osteoblastic cells at low concentrations (2-10 μg/mL) . Green tea and its constituents have also been studied for their potential to protect cells from oxidative damage. Polyphenols in green tea can protect against 1 mM H2O2 induced damage in bladder cells, with epicatechin gallate (ECG) exhibiting strong protective effects across three bladder cell lines .
The herbs white tea (Camellia sinensis Kuntze), Rose (Rosa alternifolia L.) and witch hazel (Hamamelis virginiana L.) were recently reported to have high polyphenolic contents and to exhibit high activities in antioxidant assays, along with potential anti-ageing activity via inhibition of collagenase and elastase . These herbs are often included in skin care products and are usually advertised for their astringent and antioxidant properties. In the scientific literature, white tea and witch hazel are reported for topical treatment of skin disorders. White tea has antiseptic and antioxidant properties while witch hazel has long been used for skin trouble such as acne as an astringent and antiseptic . Rose is mostly added in its essential oil form to products for its fragrance while rose water is a traditional eye lotion . The aims of this study were to further explore the anti-inflammatory activity of these plant extracts, commonly used in the skin care industry, and two formulations containing them, to assess their potential antioxidant and anti-inflammatory activity using primary human skin fibroblasts.
Plant extracts and formulations
White tea (freeze dried powder), rose (tincture), witch hazel (dried aerial herb), white tea eye gel and witch hazel distillate were supplied by Neal's Yard Remedies Ltd, Covent Garden. White tea powder (WT) and witch hazel (WH) were extracted in distilled water (500 mg in 10 mL) and then evaporated to dryness, weighed and re-constituted in water at 10 mg/mL. The rose tincture (RT) was evaporated, weighed and re-constituted in water to 10 mg/mL. The products white tea toning eye gel (WTEG) and witch hazel distillate (WHD) were diluted in distilled water to12.5% for WTEG and 50% for WHD for the assays conducted using cell cultures. Since WTEG is viscous, a dilution step (to 12.5% in media with 1% foetal bovine serum (FBS)) was required to allow the gel to permeate through the 0.2 μm filter sterilization membrane to be used in assays at 6.25, 3.125, 1.562 and 0%. The WHD affected the pH of the media and so was diluted to 50% and then used at 25, 12.5, 6.25 and 0% along with 1% FBS. All test extracts were filter sterilized in a cell culture hood prior to being further diluted in media. All extracts were stored at -20°C.
Collagenase, elastase and antioxidant assays
These assays were performed as described previously [9, 11]. Briefly, anti-collagenase activity was studied using a spectrophotometric assay using bacterial collagenase incubated with extracts for 15 minutes. Addition of the synthetic substrate N-[3-(2-Furyl)acryloyl]-Leu-Gly-Pro-Ala (FALGPA) started the reaction and was measured at 335 nm. Similarly, elastase (porcine) was incubated with extracts, then substrate N-Succinyl-Ala-Ala-Ala-p-nitroanilide (AAAPVN) was added and the reaction measured between 381 and 402 nm. Trolox equivalent antioxidant capacity was measured using the 2,2'-azino-bis(3-ethylbenzothiazoline-6-sulfonic acid diammonium salt) (ABTS+) free radical assay. A solution of ABTS+ was added to 10 μL amounts of extracts (some of which had to be diluted considerably) and measured at 730 nm. Equivalence was calculated from a trolox standard curve. Catalase activity was assessed using manometry with catalase acting as a positive control .
Results for the WTEG and WHD are shown along with the data for WT, RT and WH which were reported previously . In contrast to the previous results, where dried extracts were employed, the formulation WTEG was dissolved in water and of necessity results are shown as concentrations of 1% final volume. WHD was used neat corresponding to 10% final volume in assays.
The fibroblast cells used in this study were established from an anonymised normal skin sample and were a gift from the Institute of Cancer Research to Dr J. Peacock. Cells were cultured in Dulbecco's Modified Eagle Medium (DMEM) containing 10% FBS (PAA Gold), 5% penicillin-streptomycin solution (Fisher Scientific), and 5% L-glutamine and 5% non-essential amino acids (Sigma Aldrich). To dilute the extracts and for assays, the same medium was used except that FBS was reduced to 1% so as not to interfere with assays. Cells were kept under standard culture conditions at 37°C and 5% CO2.
IL-8 inhibition assay
Cells were seeded at approximately 1 × 104 cells/mL in 96 well culture plates in standard growth medium and grown until confluent. Once confluent, media was aspirated and 100, 50, 25 and 0 μg of extracts WT, RT, and WH extracts were added (diluted in media). WTEG and WHG formulations were diluted to 12.5% and 50% as described above. Hydrogen peroxide (filter sterilized and diluted in 1% FBS media) was added to bring the concentration within wells to 0.5 mM based on previous reports [6, 12, 13]. Control wells without H2O2 were run alongside to assess spontaneous secretion of IL-8 by cells with and without extracts. Plates were incubated for 24 hours and the supernatant collected and stored immediately at -20°C. An ELISA kit (Hycult) was then used to determine the amounts of IL-8 generated by the cells under challenge with H2O2. Standard curves containing IL-8 were also run according to the supplier's recommendation. Following kit procedure, plate absorbance values were read at 450 nm on a Cary 50 MPR and standard curves were plotted using Graphpad Prism version 5 curve fitting software.
In order to ensure the extracts were not toxic to these particular cells, cytotoxicity testing was performed according to Annan and Houghton with minor modification . Cells were diluted to approximately 1 × 104 cells/mL in media and 100 μL were added to 96 well culture plates (Nunc) to yield 1 × 103 cells/well. Cells were left overnight to adhere then the media was aspirated and replaced with media containing 1% FBS, plant extracts at concentrations between 200 and 6.25 μg amounts or products between 25 and 0.39% along with media controls. Cells were grown for 5 days before viability was assessed using the Neutral Red (NR, Sigma Aldrich) assay . Here the media was aspirated and 50 μL filtered neutral red were added (0.15% in PBS pH 5.5) and left to incubate for an hour. The dye was then removed and rinsed with PBS (pH 6.5) three times. The plates were then tapped vigorously to remove PBS prior to adding 100 μL 10% ethanolic PBS (pH 4.2) which dissolves the NR dye for uptake by the cells. After 30-60 seconds of gentle tapping and shaking, the absorbance was read at 510 nm on a Cary 50 MPR.
Microscopy to assess antioxidant activity
Cells (approximately 1 × 104 cells/mL) were seeded onto sterile, glass coverslips placed in 6-well culture plates and left to adhere overnight. The following day, wells were treated with 1% FBS media, 100 μg of WT, RT or WH or 6.25% WTEG or WHD both with and without 0.5 mM H2O2 and incubated for 24 hours. After incubation, wells were emptied and IMS added to fix the cells for 5 minutes. PBS was then used to rinse the cells twice before treating with Giemsa stain (Sigma Aldrich-diluted 1/6 in PBS) for 30 minutes. Coverslips were washed twice in PBS and left to dry. Once dry, histomount was used to mount the coverslips to the slides. Cells were then examined and photographed using a Nikon Eclipse 80i microscope.
Statistical analysis was performed using SPSS (version 17) software. Significance was taken at the 0.05 level. Levels of IL-8 between control and test samples were analysed using ANOVA and post hoc LSD. The differences between samples with and without H2O2 to show spontaneous secretion of IL-8 were analysed using the Mann-Whitney test.
Results and Discussion
Enzyme inhibition and antioxidant capacity
In comparison to the previous results for the plant extracts WH, WT and RT, the WTEG retained activity in all three assays, inhibiting collagenase and elastase by over 10% when diluted to 1%, along with a TEAC score of > 5 μmoles (Table 1). In contrast, WHD at 10% exhibited a high anti-elastase activity of ca. 41% with no detectable anti-collagenase or TEAC activities under the conditions used. The WHD does however contain 14-15% ethanol, although the final concentration of ethanol in the assay is very low (1.4-1.5%) accounting for some 10% of the elastase inhibition observed . All of the herb extracts, formulations or media that were used were assessed for catalase activity with no activity being detected. Thus, inactivation of the H2O2 by catalase activity by test samples in the cell assays can be ruled out.
Upon addition of H2O2 (0.5 mM) a significant decrease in IL-8 production was observed for all preparations compared to the media controls (p = 0.000) (Figure 1). The WT and the WH extracts exhibited the best activity ranging from 85-83% inhibition of IL-8 production. The RT extract showed the lowest inhibition which was in the range of 30-45%. For the WTEG and WHD products, the inhibition levels range from 47-58% and 36-63% respectively over the concentration range studied. Low concentrations of WTEG and WHD due to the necessary dilution steps used for the WTEG and WHD resulted in activity of circa 50%. An increase in activity might have been achieved had higher concentrations been possible. For WTEG and WHD a potential trend towards a dose response was noted but statistical analysis revealed this was not significant (p > 0.05).
A substantial amount of IL-8 is released during the experiment owing to experimental conditions. Addition of the extracts and formulations had no significant effect on this baseline IL-8 release (Figure 2) over the concentration range studied. In comparison, IL-8 release was greatly enhanced after addition of H2O2 to control samples. All test samples significantly reduced levels of IL-8 release upon addition of H2O2. There was no significant difference between the spontaneous secretion of IL-8 in the media control cells compared to the test controls (p > 0.05), which indicate low cell stress levels. Perhaps a reason for this is that in low FBS media, the cells utilise components of the extracts added. No significant differences were found between the pre- and post-H2O2 levels of IL-8 release for all test samples (p > 0.05) showing high levels of protection in each case.
Cells were examined microscopically to assess the protective effects of each test sample against H2O2 induced oxidative stress (Figure 3). There is a visible difference in the control cells upon addition of H2O2, with loss of typical fibroblast appearance, the nuclei becoming condensed and staining dark blue, revealing the occurrence of apoptosis. In contrast, upon treatment with test samples, the cells appear to remain intact and retain their shape on exposure to H2O2 (Figure 3, image 2). The WT and WH treatments exhibit greater activity against H2O2 induced damage than the products WHW and WTEG (Figure 3).
The addition of plant extracts to cell media can produce oxidative stress indirectly and has been shown by Lapidot et al. , where the phenolics interact with ingredients in the media producing H2O2. However, microscopic examination revealed that the H2O2-treated cells resemble the controls indicating that any oxidative stress caused by extracts and media may be present but was not detrimental to the cell structure (Figure 3).
Cytotoxicity profiles for each test sample were assayed using the Neutral Red dye assay (Table 2). No significant cytotoxic effects were observed. No toxicity was observed for the products WTEG and WHD. For the extracts, an increase in concentration of WT resulted in increased viability indicating potential nutritive use by the cells which negates supposed low media levels.
The observed anti-IL-8 and antioxidant activity may be owing to the polyphenolic compounds within the extracts. In general, flavonoids from plants have been found to demonstrate antioxidant activity such as kaempferol and quercetin glycosides from Carthamus tinctorius which showed a reduction in oxidative stress and damage in osteoblastic cells . Fruit extracts from Momordica charantia L. have shown in vitro antioxidant activity against H2O2 induced damage in fibroblasts and keratinocytes . As mentioned previously many plant extracts (30 screened in total) including chilli pepper, basil and licorice as well as individual flavonoids such as apigenin, kaempferol and quercetin have led to a reduction in IL-6 release by macrophages. Many of these 30 plant extracts also exhibited a positive effect reducing TNF-α and COX-2 levels as well as increasing IL-10 secretion .
Flavonoids are thought to prevent the formation of ROS by inhibiting enzymes or chelating trace metals which can mediate free radical production as well as being free radical scavengers and upregulating genetic antioxidant defences . Tea contains both kaempferol and quercetin as well as flavanols or catechins up to 30% dry weight and other acids such as gallic acid, caffeic acid and coumaric acid  which may account for the high activity seen in this study especially as a freeze-dried white tea powder was used. Catechins are powerful bioflavonoids and green tea has been shown in vivo and in vitro to have anti-inflammatory and antioxidant activity  (cited by Coyle et al. ). Epigallo-catechin-3-gallate (EGCG) is a catechin found in green and white tea and has been reported to inhibit IL-8 gene expression in respiratory epithelium cells . EGCG and other catechins can also inhibit proteins involved in inflammation, including TNF-α and xanthine oxidase .
Witch hazel leaves and bark contain up to 10% tannins, which contribute to its astringent properties. Bark contains mostly hamamelitannins and catechols while the leaves have more proanthocyanidins, ellagitannins and some essential oils . Witch hazel has been used topically as an astringent and anti-bacterial treatment for skin to alleviate inflammation caused by acne and eczema. Hamamelitannin has been investigated and found to have a significant effect on superoxide anion radical induced damage in murine fibroblast cells and exhibited higher than the activity of gallic acid, used as a positive control . The witch hazel used in this study consisted of leaves and small twigs which suggest a lower amount of hamamelitannin. However, other tannins and polyphenols such as gallic acid may be responsible for the effects as they are strong antioxidants .
Rosa centifolia flowers are the primary plant constituents in the tincture supplied for this study and contain tannins, anthocyanins, and essential oils . A flower extract from Rosa hybrida was found to have significant anti-inflammatory and analgesic activity .
The WT eye gel used in this study is made up of several ingredients including aloe vera, eyebright, rose, and witch hazel extracts as well as sodium hyaluronate which may all contribute towards its activity. No antioxidant activity was observed for hyaluronate which is the major component of glycosaminoglycans which are responsible for the hydration of the skin and also in wound healing and scar formation meaning it stimulates fibroblast proliferation . All these factors may combine synergistically to demonstrate the effects seen in this study. For the witch hazel distillate, with only addition of water and alcohol, infer the activity arises from the WH. It is also important to note that the observed anti-inflammatory effects are still significant and justify the purpose for which they are advertised.
These data show that the extracts and products tested have a protective effect on fibroblast cells against H2O2 induced damage. This approach provides a potential method to evaluate the claims made for plant extracts and the formulations in which these extracts are found.
Young CN, Koepke JI, Terlecky LJ, Borkin MS, Boyd MS, Terlecky SR: Reactive oxygen species in tumour necrosis factor-α-activated primary human keratinocytes: Implications for psoriasis and inflammatory skin disease. J Invest Dermatol. 2008, 128: 2606-2614. 10.1038/jid.2008.122.
Bickers DR, Athar M: Oxidative stress in the pathogenesis of skin disease. J Invest Dermatol. 2006, 126: 2565-2575. 10.1038/sj.jid.5700340.
Sander CS, Chang H, Hamm F, Elsner P, Thiele JJ: Role of oxidative stress and the antioxidant network in cutaneous carcinogenesis. Int J Dermatol. 2004, 43: 326-335. 10.1111/j.1365-4632.2004.02222.x.
Jenkins G: Molecular mechanisms of skin ageing. Mech Ageing Dev. 2002, 123: 801-810. 10.1016/S0047-6374(01)00425-0.
Benaiges A, Marcet P, Armengol R, Betes C, Girones E: Study of the refirming effect of a plant complex. Int J Cosmet Sci. 1998, 20: 223-233. 10.1046/j.1467-2494.1998.176608.x.
Coyle CH, Philips BJ, Morrisroe SN, Chancellor MB, Yoshimura N: Antioxidant effects of green tea and its polyphenols on bladder cells. Life Sci. 2008, 80: 12-18.
Choi EM, Kim G-H, Lee YS: Carthamus tinctorius flower extract prevents H2O2 induced dysfunction and oxidative damage in osteoblastic MC3T3-E1 cells. Phytother Res. 2010, 24: 1037-1041.
Mueller M, Hobiger S, Jungbauer A: Anti-inflammatory activity from extracts from fruits, herbs and spices. Food Chem. 2010, 122: 987-996. 10.1016/j.foodchem.2010.03.041.
Thring TSA, Hili P, Naughton DP: Anti-collagenase, anti-elastase and anti-oxidant activities of extracts from 21 plants. BMC Complement Altern Med. 2009, 9: 27-10.1186/1472-6882-9-27.
Van Wyk BE, Wink M: Medicinal plants of the world. 2004, Pretoria, South Africa: Briza publications
Fisher AEO, Maxwell SC, Naughton DP: Catalase and superoxide dismutase mimics for the treatment of inflammatory diseases. Inorg Chem Commun. 2003, 6 (9): 1205-1208. 10.1016/S1387-7003(03)00223-5.
Annan K, Houghton PJ: Antibacterial, antioxidant and fibroblast growth stimulation or aqueous extracts of Ficus asperifolia Miq. and Gossypium arborerum L., wound-healing plants of Ghana. J Ethnopharmacol. 2008, 119: 141-144. 10.1016/j.jep.2008.06.017.
Kumar R, Balaji S, Sripriya R, Nithya N, Uma TS, Sehgal PK: In vitro evaluation of antioxidants of fruit extract of Momordica charantia L. on fibroblasts and keratinocytes. J Agr Food Chem. 2010, 28: 1518-1522.
Doyle A, Griffiths JB: Cell and tissue culture for medical research. 2000, West Sussex, England: John Wiley and Sons Ltd
Winninger C, Lestienne P, Dimicoli JL, Bieth JG: NMR and enzymatic investigation of the interaction between elastase and sodium trifluoracetate. Biochim et Biophys Acta. 1978, 526: 227-234.
Lapidot T, Walker MD, Kanner J: Can apple antioxidants inhibit tumour cell proliferation? Generation of H2O2 during interaction of phenolic compounds with cell media. J Agr Food Chem. 2002, 50: 3156-3160. 10.1021/jf011522g.
Pietta P-G: Flavonoids as antioxidants. J Natural Products. 2000, 63: 1035-1042. 10.1021/np9904509.
Yang CS, Lee MJ, Chen L: Human salivary tea catechin levels and catechin esterase activities: implication in human cancer prevention studies. Cancer Epidem Biomar. 1999, 8: 83-89.
Chen PC, Wheeler DS, Malhotra V, Odoms K, Denenberg AG, Wong H: A green tea-derived polyphenol, epigallocatechin-3-gallate, inhibits IκB kinase activation and IL-8 gene expression in respiratory epithelium. Inflammation. 2002, 26: 233-241. 10.1023/A:1019718718977.
Masaki H, Atsumi T, Sakurai H: Protective activity of hamamelitannin on cell damage induced by superoxide anion radicals in murine dermal fibroblasts. Biol Pharm Bull. 1995, 18: 59-63. 10.1248/bpb.18.59.
Choi E-M, Hwang JK: Investigations of anti-inflammatory and antinociceptive activities of Piper cubeba, Physalis angulata and Rosa hybrida. J Ethnopharmacol. 2003, 89: 171-175. 10.1016/S0378-8741(03)00280-0.
Price RD, Berry MG, Navsaria HA: Hyaluronic acid: the scientific and clinical evidence. J Plast Reconstr Aesthet Surg. 2007, 60: 1110-1119. 10.1016/j.bjps.2007.03.005.
Dr. John Peacock and Delphine Thenet for supplying cells and advice. NYR and Kingston University for funding project. Prof. Andrea Petroczi for statistical advice.
PH is an employee of Neal's Yard Remedies Ltd, which in part funded the studentship for TT.
The authors declare that they have no competing interests.
TT, PH, and DPN participated in the design of the study data analyses and manuscript preparation. TT conducted the assays and analyses. All authors read and approved the final manuscript.
